Cooper & Hunter | Mia NY Series
Model: CH-RLS06MIA-115VO
BTU
9,000
SEER2
21.5
Voltage
115V, 1Ph, 60Hz V, Ph, Hz
Refrigerant
R454B
Indoor: CH-RLS06MIA-115VI
Cooper & Hunter's Mia NY Series is an entry-level indoor wall-mounted mini split offering an affordable yet energy-efficient solution. This series provides both cooling and heating in a single unit and is equipped with innovative features. The 115V units are available in 6K, 9K, and 12K Btu/h while the 230V units are offered in 9K, 12K, 18K, and 24K Btu/h. The Mia NY Series features a sleek, matte finish and achieves up to a 21.7 SEER2 rating for effective energy efficiency.
| Indoor Model | CH-RLS06MIA-115VI |
| Power supply | 115V, 1Ph, 60Hz V, Ph, Hz |
| Communication wiring | AWG 14-4 |
| Cooling Capacity | 9,000 (2,200~9,900) Btu/h |
| EER/EER2 | 12.5 Btu/w |
| SEER/SEER2 | 21.5 Btu/w |
| Heating at 47 °F Capacity | 10,000 (4,200~10,200) Btu/h |
| Input | 890 (260~950) W |
| Rated current | 9.8 (1.4~10.2) A |
| Indoor fan motor | 1 Qty |
| ESP (range) | / ln.wg. |
| Drainage water pipe diameter | 5/8" inch |
| Design pressure | 550/340 PSIG |
| Controller | remote controller |
| Room temperature Cooling | 60~90 F |
| Heating | 5 ~ 75 F |
| Outdoor Model | CH-RLS06MIA-115VO |
| Type | ROTARY |
| Brand | GMCC |
| Refrigerant Type | R454B |
| Precharge | 25 ft |
| Additional charge for 1/4 inch liquid pipe | 0.16 oz |
| Ambient temperature Cooling | 5 ~ 122 F |
