OLMO Wall Mount

Olmo 5-Zone Mini Split AC & Heat Pump -- 42000 (3.5 Ton), Wall Mount Units (9K+9K+9K+12K+24K BTU), Inverter Technology, 230V, Heating & Cooling - R454B

Summary

The OLMO Sierra Multi-Zone can be used in multiple combinations with Olmo Multi-Sierra Wall Mounted Units in up to 5 independent zones. Featuring inverter technology, this heat pump offers up to 25 SEER2 ratings, delivering efficient cooling and heating capabilities. With Smart Connect included, you can independently control this unit from anywhere using the APP for added comfort and convenience. A remote control is also included, offering features such as Sleep, Turbo, and Eco modes, Multiple Fan Speeds, Timer, and Auto Swing Louvers.

Important

All units must be installed by a licensed HVAC professional for the warranty to be valid. Registration is required within 60 days of installation and can be completed online or by phone. The installation kit is necessary for the system to function. Ensure that you have selected the desired installation kit above. This kit comes with Pre-Flared 99% Copper Lines, Data Communication Wires, PVC Drainage Attachment, Wrapping Bands, etc.

Included in Your Order

Olmo Wall Mounted Mini Split System

Outdoor Unit: 42,000 BTU (1 pc) - Model: OS-RMS42-230VO

Indoor Units:

- 9,000 BTU (3 pcs) - Model: OS-RM09SW-230VI

- 12,000 BTU (1 pcs) - Model: OS-RM12SW-230VI

- 24,000 BTU (1 pcs) - Model: OS-RM24SW-230VI

Optional, Pre-Flared 99% Copper Installation Kit (16ft, 25ft or 50ft.)

Wireless Remote Controls (5 remotes)

Installation Manual

User's Manual

Manufacturer Warranty

Complete Technical Specifications

Indoor Unit: OS-RM09SW-230VI (9,000 BTU) x3

Voltage range (V) 187-253

SEER2 up to 25

Refrigerant type R454B

Refrigerant piping Liquid/Gas side (inch) 1/4"/3/8"

Packing dimensions (WxDxH) 34 1/4x13 3/16x10 7/16

Filter dimensions (WxDxH)
